| DS-2CD5585G0-IZS(2.8-12mm) |
| Camera |
| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Min. Illumination |
|
Color: 0.002 Lux @ (F1.2, AGC ON), 0.005 Lux @ (F1.8, AGC ON), 0 Lux with IR
|
|
|
|
| Shutter Speed |
1 s to 1/100,000 s |
| Angle Adjustment |
Bracket, pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 360° |
| Slow Shutter |
Yes |
| Day & Night |
IR Cut Filter |
| WDR |
140 dB |
| Lens |
| Lens Type |
Motorized lens, 2.8 to 12 mm and 8 to 32 mm optional |
| Aperture |
2.8 to 12 mm @ F1.2 to F2.5 |
| Focus |
Auto, semi-auto, manual |
| Auto-iris |
|
| Lens Mount |
Integrated |
| FOV |
2.8 to 12 mm, horizontal FOV 109.2° to 38.9°, vertical FOV 56.2° to 21.9°, diagonal FOV 134.5° to 45° |
| Illuminator |
| IR Range |
|
| Wavelength |
850nm
|
| Video |
| Max. Resolution |
|
| Video Stream |
5 defined streams and up to 5 custom stream |
| Main Stream |
|
50Hz: 25fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60Hz: 30fps (2560 × 1440, 1920 × 1080, 1280 × 720)
|
|
| Sub Stream |
50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480) |
| Third Stream |
|
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
|
|
| Fourth Stream |
|
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
|
|
| Fifth Stream |
|
50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480)
|
|
| Custom Stream |
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) 480) |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264
Sub stream/third stream/fourth stream/fifth stream/custom stream: H.265/H.264/MJPEG
|
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.264+ |
Main stream support |
| H.265 Type |
Main Profile |
| H.265+ |
Main stream support |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM |
| Audio Bit Rate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM) |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Smart Feature Set |
| Smart Event |
Line crossing detection, up to 4 lines configurable Intrusion detection, up to 4 regions configurable Region entrance detection, up to 4 regions configurable Region exiting detection, up to 4 regions configurable Unattended baggage detection, up to 4 regions configurable Object removal detection, up to 4 regions configurable Face detection: detects faces and upload images Scene change detection, audio exception detection, defocus detection |
| Basic Event |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Statistics |
Counting |
| Linkage Method |
Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email |
| Region of Interest |
|
Main stream/sub stream/third stream/fourth stream/fifth stream: 4 fixed regions for each stream
|
|
| Image |
| Image Enhancement |
BLC, HLC, Defog, EIS, Distortion Correction |
| Image Setting |
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser |
| Target Cropping |
Yes |
| Day/Night Switch |
Day/Night/Auto/Schedule/Triggered by Alarm In |
| Picture Overlay |
LOGO picture can be overlaid on video with 128 × 128 24bit bmp format |
| Network |
| Network Storage |
microSD/SDHC/SDXC card (256 G), local storage and NAS (NFS, SMB/CIFS), ANR Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| API |
ONVIF® (PROFILE S, PROFILE G), ISAPI, SDK |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| Smooth Streaming |
Yes |
| Security |
|
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, TLS1.0, TLS1.1
|
|
| Simultaneous Live View |
Up to 20 channels |
| User/Host |
Up to 32 users. 3 user levels: administrator, operator and user |
| Client |
iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser |
Plug-in required live view: IE8+, Chrome 41.0-44, Mozilla Firefox 30.0-51, Safari8.0-11 Plug-in free live view: Chrome 45+, Mozilla Firefox 52+ |
| Interface |
| Audio |
1-ch 3.5 mm input (line in), 1-ch 3.5mm output, mono |
| Communication Interface |
1 RJ45 10M/100M/1000M self-adaptive Ethernet port, RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
| Alarm |
|
2 inputs, 2 outputs (max. 24 VDC/VAC, 1A)
|
|
| Video Output |
1Vp-p composite output (75 Ω/CVBS), only for adjustment |
| Power Output |
12 VDC, max. 200mA |
| On-board storage |
Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| General |
| Firmware Version |
5.5.90 |
| Web Client Language |
32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| General Function |
Anti-flicker, 5 streams and up to 5 custom streams, heartbeat, mirror, password protection, regions of privacy mask, flash log, password reset via e-mail, pixel counter, control timeout setting |
| Reset |
Reset via reset button on camera body, web browser and client software |
| Startup and Operating Conditions |
-30 °C to 65 °C (-22 °F to 149 °F), -H: -40 °C to 65 °C (-40 °F to 149 °F) Humidity 95% or less (non-condensing) |
| Storage Conditions |
-30 °C to 65 °C (-22 °F to 149 °F) Humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC is recommended, 10 to 48 VDC, two-core terminal block, reverse polarity protection PoE (802.3at, class 4) |
| Power Consumption and Current |
With extra load: 12 VDC, 1.1 A, max. 12 W; PoE (802.3at, 42.5 V to 57 V), 0.3 A to 0.2 A, class 4 Without extra load: 12 VDC, 0.95 A, max. 10 W; PoE (802.3at, 42.5 V to 57 V), 0.3 A to 0.2 A, class 4 “with extra load” means that an extra device is connected to and powered by the camera. |
| Material |
Metal |
| Dimensions |
Camera: Φ144 × 347 mm (Φ5.7ʺ × 13.7ʺ) With package: 405 × 190 × 180 mm (15.9ʺ × 7.5ʺ × 7.1ʺ) |
| Weight |
|
Camera: approx. 1.85 kg (4.07 lb.) With package: approx. 2.95 kg (6.50 lb.)
|
|
| Approval |
|
| EMC |
|
47 CFR Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32: 2015, KN 35: 2015
|
|
| Safety |
UL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IS 13252(Part 1):2010+A1:2013+A2:2015
|
| Chemistry |
|
2011/65/EU, 2012/19/EU, Regulation (EC) No 1907/2006
|
|
| Protection |
Ingress protection: IK10 (IEC 62262:2002), IP67 (IEC 60529-2013)
|
